Specifications – SSW Series
Code: SSW
Standard Cabinet Dimensions: Base cabinets 34-1/2” H × 24” D; wall cabinets 12” D
Construction: 3/4” plywood cabinet box with MDF doors
Finish: White, UV-painted finish
Door Style: Modern Slim Shaker
Door & Drawer Fronts: Full overlay, 7/8” thick MDF
Cabinet Construction: European-style frameless design
Cabinet Box: 3/4” thick, 13-ply plywood with white melamine interior or painted finish; assembled using cam-lock system or screw & dowel construction
Drawers: Option 1 – 5-piece dovetail drawers with 5/8” solid wood (birch veneer) sides & back, 3/8” plywood bottom; Option 2 – DTC metal drawer system
Shelving: 3/4” plywood shelves with white melamine or painted finish, supported by metal shelf pins
Cabinet Sides: Finished end panels available for exposed sides
Wall Cabinets: Available in 30”, 36”, and 42” heights; finished bottoms; end panels available as required
Hardware: DTC concealed 6-way adjustable soft-closing hinges; DTC under-mount full extension soft-closing drawer slides with 6-way adjustable clips
Vanities: Matching bathroom vanities available in multiple sizes
Note: Product images are for reference only. Actual colors may vary slightly due to lighting, photography, and display settings.
